MaxiBAS BT609

The MaxiBAS BT609 wireless battery and diagnostics system applies Adaptive Conductance, an advanced battery analysis method that produces a more accurate examination of the battery’s cold cranking ability and reserve capacity, vital to determining a battery’s true health. The 7-inch Android touchscreen tablet can display a quick health status of the existing battery, register a new battery and perform advanced battery and electrical system diagnostics. The BT609’s features include AutoVIN to immediately identify vehicle and battery information and to display graphic instructions for battery positioning and testing. Features service menu. Read/Clear codes on all available vehicle systems and perform common maintenance services. Print or share customized reports via Wi-Fi.


  • image 0
  • image 0
  • image 0

    Support in-vehicle and out-of-vehicle testing of passenger vehicle batteries.



    Test 6- and 12-volt batteries: 100 – 3000 CCA



    Test 12- and 24-volt cranking/charging systems



    Test Flooded, AGM, AGM Spiral, EFB and GEL batteries



    Compatible with CCA, CA, SAE, EN, IEC, DIN, JIS and MCA



    Quick display of battery specifications through battery barcode scan, auto and manual VIN entry



    Illustration instruction guides for battery positioning and testing



    Read and erase codes and view Live Data of all available systems



    Support maintenance services


ItemDescription
Operating SystemAndroid 9.0
Memory2GB RAM &   64GB On-board Memory
Display7.0 inch   TFT-LCD with 1280 x 800 resolution & capacitive touch screen
ConnectivityWi-Fi (IEEE   802.11 a/b/g/n/ac 1x1)
BT 5.0+EDR+BLE
 USB 2.0 (1 USB HOST + 1 USB OTG)
Micro SD Card (Support up to 128GB)
Camera8 Megapixel
SensorAmbient Light   Sensor (ALS)
Audio Microphone
Input/Output Loudspeaker
Power and Battery5800 mAh 3.85 V   lithium-polymer battery
Charging via 5 V AC/DC power supply with the temperature between   0°C and 45°C
Input Voltage5 V / 2 A   Adapter
Operating Temp.0 to 50° C (32 to 122° F)
Storage Temp.-10 to 60° C   (14 to 140° F)
Dimensions (WxHxD)197 mm   (7.75") x 135 mm (5.31") x 14 mm (0.55")
Weight445 g (0.98 lb.)


Autel BT609 Battery Analyzer & Diagnostics Tablet

  • Description
  •     Support in-vehicle and out-of-vehicle testing of passenger vehicle batteries.



        Test 6- and 12-volt batteries: 100 – 3000 CCA



        Test 12- and 24-volt cranking/charging systems



        Test Flooded, AGM, AGM Spiral, EFB and GEL batteries



        Compatible with CCA, CA, SAE, EN, IEC, DIN, JIS and MCA



        Quick display of battery specifications through battery barcode scan, auto and manual VIN entry



        Illustration instruction guides for battery positioning and testing



        Read and erase codes and view Live Data of all available systems



        Support maintenance services


  • Specifications
  • ItemDescription
    Operating SystemAndroid 9.0
    Memory2GB RAM &   64GB On-board Memory
    Display7.0 inch   TFT-LCD with 1280 x 800 resolution & capacitive touch screen
    ConnectivityWi-Fi (IEEE   802.11 a/b/g/n/ac 1x1)
    BT 5.0+EDR+BLE
     USB 2.0 (1 USB HOST + 1 USB OTG)
    Micro SD Card (Support up to 128GB)
    Camera8 Megapixel
    SensorAmbient Light   Sensor (ALS)
    Audio Microphone
    Input/Output Loudspeaker
    Power and Battery5800 mAh 3.85 V   lithium-polymer battery
    Charging via 5 V AC/DC power supply with the temperature between   0°C and 45°C
    Input Voltage5 V / 2 A   Adapter
    Operating Temp.0 to 50° C (32 to 122° F)
    Storage Temp.-10 to 60° C   (14 to 140° F)
    Dimensions (WxHxD)197 mm   (7.75") x 135 mm (5.31") x 14 mm (0.55")
    Weight445 g (0.98 lb.)
