MaxiIM IM608 PRO

OBD2 Diagnostics And Key Fob Programmer With JVCI Tool Bundle

MaxiIM IM608 PRO is the most advanced and unique all in one key programming and diagnostic tool that combines advanced key programming, all systems diagnostics, and advanced services in one Android based 10.1-inch touchscreen tablet. It is equipped with XP400 PRO key programmer and MaxiFlash ECU programmer to provide complete coverage of IMMO and programming functions. IM608 PRO provides you with all special functions to quickly diagnose all modules for the majority of the makes and models on the market. It is the unprecedented key programming and diagnostic tool that you ever wanted.




  • image 0
  • image 0
  • image 0

• Samsung Exynos 5260(2GB ROM)


• 10.1”1024x768 LCD capacitive touchscreen


• Internal reliable 64GB Memory


• Android Operating System for fast boot-up and multitasking


• Powerful combination of key programming/all system diagnostics/advanced maintenance services


• Smart Mode for guided and automated key learning


• Expert Mode for advanced key learning


• Read PIN/CS (all key lost) , key generation, key learning, remote learning


• IMMO ECU reset/adaptation, refresh/coding


• Transpronder read/write, EEPROM/MCU read/write



• Powerful OE level diagnostics for more than 80 US, Asian and European makes and models


• Advanced maintenance services including EPB, DPF, SAS, Oil reset, and BMS

Operating SystemAndroid™ 4.4.2, KitKat
ProcessorSamsung Exynos hexa-core Processor (1.3GHz Quad-core ARM Cortex-A7 + 1.7GHz Dual-core ARM Cortex-A15)
Memory2GB RAM & 64GB On-board Memory
Display10.1-inch LED capacitive touch screen with 1920x1200 resolution
Connectivity

Wi-Fi (802.11 a/b/g/n/ac)

USB: 2.0

BT v.2.1 + EDR

SD Card (Support up to 32GB)

HDMI

SensorsGravity Accelerometer, Ambient Light Sensor (ALS)
Power and Battery

15000 mAh 3.8 V lithium-polymer battery

Charging via 12 V AC/DC power supply with the temperature between 0°C and 45°C
Input Voltage12 V (9-24 V)
Power Consumption6.5 W
Operating Temp0 to 50°C (32 to 122°F)
Storage Temp-20 to 60°C (-4 to 140°F)
Dimensions (WxHxD)300 mm (11.81”) x 220 mm (8.66”) x 50 mm (1.97”)
Weight

NW: 1.42 kg (3.13 lb.)

GW: 8.655 kg (19.08 lb.)

Protocols


ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, CAN ISO 11898, Highspeed, Middlespeed, Lowspeed and Singlewire CAN, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP 2.0, TP 1.6, SAE J1939, SAE J1708, Fault-Tolerant CAN
  • IM608PRO & IMKPA Key Programming Adapter Set Webcast Training

  • Autel IM608 Pro Introduction and Unboxing | Key programming

  • Need a new Honda key? Follow these tips and get a new key fast!

  • Autel IM608 Pro | Make a car key without original one | Key programming

  • How to program a new on Mercedes-Benz | Autel IM608 Pro

  • Lost all keys? 5 minutes to get your lost Mercedes Benz car keys replaced!

  • How to do EEPROM Programming with a Porsche

˜ Standard Functions  ▲Need extra adapters   △ Need XP400 Pro   ○ Need XP400 Pro and extra adapters


IM508

IM608 PRO

Programming

EEPROM Read/Write

Basic

Advanced

MCU Read/Write

Basic

Advanced

Immobilizer Read/Write

˜

Advanced

Engine Read/Write

˜

Advanced

Mercedes Infrared Key Read/Write



˜

Remote Frequency Detection



˜

IMMO



Smart Mode(Guided and   Automated Key Learning Function)

˜

˜

Auto Detect Make/Model/Year/System

˜

˜

Read PIN(Add   Key/All   Key   Lost)

˜

˜

Key Generation/Key Learning/Remote Learning

˜

˜

IMMO ECU Reset/Adaption

˜

˜

IMMO ECU Refresh/Coding

˜

˜

Backup/Restore IMMO Data

˜

˜

BENZ 3rd Generation IMMO   Add Key, All Key Lost via OBD



˜

Read/Write/Erase Benz ESL_W209 / W906 Data





Benz OE NEC Key Learning





Volkswagen MQB Key Learning via OBD

˜

˜

Volkswagen/Audi 4th Generation IMMO Key Learning

˜

˜

Volkswagen/Audi 5th Generation IMMO Key Learning

˜

˜

BMW FEM/BDC Key Learning and Adaption

˜

˜

BMW CAS4/3/2/1 Key Learning

˜

˜

BMW EWS3 Key Learning



▲

2015-2019 Jaguar Land Rover Write Key via Dump



˜

Volvo Smart Key/Fobik Smart Key Learning



˜

Volkswagen/AUDI/BMW Key Unlock





OE-Level Diagnostics

All Systems for Over 80 Makes

˜

˜

MaxiFlash JVCI (J2534 ECU Reprogrammer)


˜

ECU Coding


˜

Active Test


˜

Complete Service Functions

Basic

Advanced

Features



Rechargeable Li-ion Battery

5000 mAh

15000 mAh

Internet Updatable

Wi-Fi

Wi-Fi

Multilingual Support

˜

˜

Limited One Year Warranty

˜

˜

Touchscreen

7-inch

10.1-inch

Memory

32GB

64GB

Processor

Quad-core

Hexa-core

Camera


8.0 Megapixel

Resolution

1024x600

1920x1200



Note: XP400 Pro can be purchased separately.

Some listed functions are manufacture dependent. Constantly update MaxiIM for current vehicle coverage. Update software on a regular basis to get the latest tool features.

  • Description
  • • Samsung Exynos 5260(2GB ROM)


    • 10.1”1024x768 LCD capacitive touchscreen


    • Internal reliable 64GB Memory


    • Android Operating System for fast boot-up and multitasking


    • Powerful combination of key programming/all system diagnostics/advanced maintenance services


    • Smart Mode for guided and automated key learning


    • Expert Mode for advanced key learning


    • Read PIN/CS (all key lost) , key generation, key learning, remote learning


    • IMMO ECU reset/adaptation, refresh/coding


    • Transpronder read/write, EEPROM/MCU read/write



    • Powerful OE level diagnostics for more than 80 US, Asian and European makes and models


    • Advanced maintenance services including EPB, DPF, SAS, Oil reset, and BMS

  • Specifications
  • Operating SystemAndroid™ 4.4.2, KitKat
    ProcessorSamsung Exynos hexa-core Processor (1.3GHz Quad-core ARM Cortex-A7 + 1.7GHz Dual-core ARM Cortex-A15)
    Memory2GB RAM & 64GB On-board Memory
    Display10.1-inch LED capacitive touch screen with 1920x1200 resolution
    Connectivity

    Wi-Fi (802.11 a/b/g/n/ac)

    USB: 2.0

    BT v.2.1 + EDR

    SD Card (Support up to 32GB)

    HDMI

    SensorsGravity Accelerometer, Ambient Light Sensor (ALS)
    Power and Battery

    15000 mAh 3.8 V lithium-polymer battery

    Charging via 12 V AC/DC power supply with the temperature between 0°C and 45°C
    Input Voltage12 V (9-24 V)
    Power Consumption6.5 W
    Operating Temp0 to 50°C (32 to 122°F)
    Storage Temp-20 to 60°C (-4 to 140°F)
    Dimensions (WxHxD)300 mm (11.81”) x 220 mm (8.66”) x 50 mm (1.97”)
    Weight

    NW: 1.42 kg (3.13 lb.)

    GW: 8.655 kg (19.08 lb.)

    Protocols


    ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, CAN ISO 11898, Highspeed, Middlespeed, Lowspeed and Singlewire CAN, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP 2.0, TP 1.6, SAE J1939, SAE J1708, Fault-Tolerant CAN
  • Video
  • Comparison
  • ˜ Standard Functions  ▲Need extra adapters   △ Need XP400 Pro   ○ Need XP400 Pro and extra adapters


    IM508

    IM608 PRO

    Programming

    EEPROM Read/Write

    Basic

    Advanced

    MCU Read/Write

    Basic

    Advanced

    Immobilizer Read/Write

    ˜

    Advanced

    Engine Read/Write

    ˜

    Advanced

    Mercedes Infrared Key Read/Write



    ˜

    Remote Frequency Detection



    ˜

    IMMO



    Smart Mode(Guided and   Automated Key Learning Function)

    ˜

    ˜

    Auto Detect Make/Model/Year/System

    ˜

    ˜

    Read PIN(Add   Key/All   Key   Lost)

    ˜

    ˜

    Key Generation/Key Learning/Remote Learning

    ˜

    ˜

    IMMO ECU Reset/Adaption

    ˜

    ˜

    IMMO ECU Refresh/Coding

    ˜

    ˜

    Backup/Restore IMMO Data

    ˜

    ˜

    BENZ 3rd Generation IMMO   Add Key, All Key Lost via OBD



    ˜

    Read/Write/Erase Benz ESL_W209 / W906 Data





    Benz OE NEC Key Learning





    Volkswagen MQB Key Learning via OBD

    ˜

    ˜

    Volkswagen/Audi 4th Generation IMMO Key Learning

    ˜

    ˜

    Volkswagen/Audi 5th Generation IMMO Key Learning

    ˜

    ˜

    BMW FEM/BDC Key Learning and Adaption

    ˜

    ˜

    BMW CAS4/3/2/1 Key Learning

    ˜

    ˜

    BMW EWS3 Key Learning



    ▲

    2015-2019 Jaguar Land Rover Write Key via Dump



    ˜

    Volvo Smart Key/Fobik Smart Key Learning



    ˜

    Volkswagen/AUDI/BMW Key Unlock





    OE-Level Diagnostics

    All Systems for Over 80 Makes

    ˜

    ˜

    MaxiFlash JVCI (J2534 ECU Reprogrammer)


    ˜

    ECU Coding


    ˜

    Active Test


    ˜

    Complete Service Functions

    Basic

    Advanced

    Features



    Rechargeable Li-ion Battery

    5000 mAh

    15000 mAh

    Internet Updatable

    Wi-Fi

    Wi-Fi

    Multilingual Support

    ˜

    ˜

    Limited One Year Warranty

    ˜

    ˜

    Touchscreen

    7-inch

    10.1-inch

    Memory

    32GB

    64GB

    Processor

    Quad-core

    Hexa-core

    Camera


    8.0 Megapixel

    Resolution

    1024x600

    1920x1200



    Note: XP400 Pro can be purchased separately.

    Some listed functions are manufacture dependent. Constantly update MaxiIM for current vehicle coverage. Update software on a regular basis to get the latest tool features.
