MaxiCheck MX808S

When it comes to ultra-portability, MaxiCheck MX808S is your perfect companion. Installed with a fast quad-core processor, MX808S offers maximum convenience and swift diagnosis. The intuitive user screen makes using the device effortless through a 7-inch LCD touchscreen that displays at 1024 x 600 quality. Together with the ability to quickly read and clear DTCs for all available modules of the majority of the makes and models on the market, MX808S provides you with superior special functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), BMS (Battery Management System), DPF (Diesel Particulate Filter), IMMO, and TPMS (Tire Pressure Monitoring System).

  • image 1

• Read and erase codes for all available systems


• View and graph Live Data


• AutoVIN technology automatically identifies vehicle make, model, and year


• Perform bi-directional Active Tests, perform Coding and Adaptations


• Powerful Cortex-A55 processor (1.8 GHz) processor


• 7-inch LCD capacitive touchscreen with 1024 x 600 resolution display


• 64GB on-board memory for better performance


• Android 11 operating system for fast boot-up and multitasking


• Reset Steering Angle Sensor (SAS)


• Reset service mileage and service intervals


• Reset Electronic Parking Brake


• Perform DPF regeneration


• Reset Injectors


• Support battery registration and reset


• Compatible with Videoscope


Display7-inch LCD capacitive touchscreen with 1024x600 resolution
ConnectivityWi-Fi(802.11a/b/g/n/ac)
USB 2.0,Mini USB 2.0
SD Card (Support up to 64GB)
SensorsLight sensor for brightness auto adjust
Audio Input/OutputInput: N/A
Output: Beep
Power and Battery3.7 V/5000mAh lithium-polymer battery
Charges via 5 VDC power supply
Input Voltage5 V/1.5 A
Operating Temp0 to 50°C (32 to 122°F)
Storage Temp -10 to 60 (14 to 140°F)
Dimensions(WXHX D)270.8 mm (10.0”) x 176.0 mm(6.9”) x 36.0 mm (1.4”)
Weight885 g (2.31 lb.)
Protocols
ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing   Code, SAE-J1850 VPW, SAE-J1850PWM,   ISo11898(Highspeed, Middlespeed, Lowspeed    and Singlewire CAN, fault-tolerant CAN) SAE J2610, GM UART UART Echo   Byte Protocol, Honda Diag-H Protocol,TP2.0,TP1.6



MaxiCheck MX808SMaxiCheck MX808S-TSMaxiCheck MX808
Read Codes
Erase Codes
Live Data
ECU Information
Active Test
Service Functions
Complete OBD Diagnositcs
Oil Serive Reset
Parking Brake Pad Relearn After   Replacement
Steering Angle Sensor Relearn
Battery Registration and Reset
Diesel Particulate Filter Regeneration
Tire Pressure Monitoring SystemBasicCompleteBasic
Immobilizer FunctionBasicBasicBasic
Advanced TPMS Diagnostics for Complete   TPMS Health Check----
Activate 98% of All Known TPMS Sensors----
Program AUTEL MX-Sensors----
Comprehensive OBD relearn coverage----
On-screen Relearn Procedure----
Battery Analysis----
Videoscope
ProcessorQuad-core 1.8GHzQuad-core 1.8GHzQuad-core 1.6GHz
Operating SystemAndroid 11Android 11Android 4.4.4
Memory4G + 64G4G + 64G1G + 64G
Display7" LCD7" LCD7" LCD
Battery5000 mAh5000 mAh5000 mAh
Internet UpdatableWiFiWiFiWiFi
Multilingual Support
Historical Test Records
Save and Playback Data
Print Data via Windows PC
Vehicle communication methodWiredWireless (bluetooth)Wired


  • Description
  • • Read and erase codes for all available systems


    • View and graph Live Data


    • AutoVIN technology automatically identifies vehicle make, model, and year


    • Perform bi-directional Active Tests, perform Coding and Adaptations


    • Powerful Cortex-A55 processor (1.8 GHz) processor


    • 7-inch LCD capacitive touchscreen with 1024 x 600 resolution display


    • 64GB on-board memory for better performance


    • Android 11 operating system for fast boot-up and multitasking


    • Reset Steering Angle Sensor (SAS)


    • Reset service mileage and service intervals


    • Reset Electronic Parking Brake


    • Perform DPF regeneration


    • Reset Injectors


    • Support battery registration and reset


    • Compatible with Videoscope


  • Specifications
  • Display7-inch LCD capacitive touchscreen with 1024x600 resolution
    ConnectivityWi-Fi(802.11a/b/g/n/ac)
    USB 2.0,Mini USB 2.0
    SD Card (Support up to 64GB)
    SensorsLight sensor for brightness auto adjust
    Audio Input/OutputInput: N/A
    Output: Beep
    Power and Battery3.7 V/5000mAh lithium-polymer battery
    Charges via 5 VDC power supply
    Input Voltage5 V/1.5 A
    Operating Temp0 to 50°C (32 to 122°F)
    Storage Temp -10 to 60 (14 to 140°F)
    Dimensions(WXHX D)270.8 mm (10.0”) x 176.0 mm(6.9”) x 36.0 mm (1.4”)
    Weight885 g (2.31 lb.)
    Protocols
    ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing   Code, SAE-J1850 VPW, SAE-J1850PWM,   ISo11898(Highspeed, Middlespeed, Lowspeed    and Singlewire CAN, fault-tolerant CAN) SAE J2610, GM UART UART Echo   Byte Protocol, Honda Diag-H Protocol,TP2.0,TP1.6


  • Video
  • Comparison

  • MaxiCheck MX808SMaxiCheck MX808S-TSMaxiCheck MX808
    Read Codes
    Erase Codes
    Live Data
    ECU Information
    Active Test
    Service Functions
    Complete OBD Diagnositcs
    Oil Serive Reset
    Parking Brake Pad Relearn After   Replacement
    Steering Angle Sensor Relearn
    Battery Registration and Reset
    Diesel Particulate Filter Regeneration
    Tire Pressure Monitoring SystemBasicCompleteBasic
    Immobilizer FunctionBasicBasicBasic
    Advanced TPMS Diagnostics for Complete   TPMS Health Check----
    Activate 98% of All Known TPMS Sensors----
    Program AUTEL MX-Sensors----
    Comprehensive OBD relearn coverage----
    On-screen Relearn Procedure----
    Battery Analysis----
    Videoscope
    ProcessorQuad-core 1.8GHzQuad-core 1.8GHzQuad-core 1.6GHz
    Operating SystemAndroid 11Android 11Android 4.4.4
    Memory4G + 64G4G + 64G1G + 64G
    Display7" LCD7" LCD7" LCD
    Battery5000 mAh5000 mAh5000 mAh
    Internet UpdatableWiFiWiFiWiFi
    Multilingual Support
    Historical Test Records
    Save and Playback Data
    Print Data via Windows PC
    Vehicle communication methodWiredWireless (bluetooth)Wired
