MaxiDAS DS808

Based on the Android operating system, MaxiDAS DS808 is featured with an extensive coverage of OE-level diagnostics. Installed with a fast quad-core processor, DS808 offers maximum convenience and efficiency for your diagnosis and analysis. The intuitive user interface makes using the device effortless through a 7-inch LCD touchscreen that displays at 1024 x 600 quality.


  • image 1
  • image 1

• Extensive vehicle coverage for more than 80 US, Asian and European vehicle makes


• Exceptional OE-Level system coverage for all electronic systems


• Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, etc.


• Smart AutoVIN technology for identifying vehicles easily


• Automatic system and software updates with real-time push message notifications via Wi-Fi


• Instant remote control tech support anytime, anywhere


• Cloud-based MaxiFix online community provides proven filed fixes


• Interactive Data Logging sessions enable direct contact with Autel Technical Support for first-hand troubleshooting of diagnostic bugs and errors


• One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized


• Convenient data management system for managing internal program applications and reviewing data


• NEW!Compatible with Videoscope

Recommended UseIndoor
Operating SystemAndroid™ 4.4.4
ProcessorCortex-A9 processor (1.6 GHz)
Memory64GB
Display7-inch LCD capacitive touchscreen with 1024x600 resolution
Connectivity

Mini USB 2.0

USB 2.0

Wi-Fi

Micro SD card (supports up to 32GB)

SensorsAmbient light sensor for brightness auto changing
Audio Input/Output

Input: N/A

Output: buzzer

Power and Battery

 3.7 V/5000 mAh lithium-polymer battery

 Charges via 5 VDC power supply

Tested Battery LifeAround 4.5 hours of continuous use
Battery Charging Input5 V/1.5 A
Power Consumption500 mA (LCD on with default brightness, Wi-Fi on) @3.7 V
Operating Temp-10 to 60°C(14 to 140°F)
Storage Temp-20 to 70°C (-4 to 158°F)
Operating Humidity5% - 95% non-condensing
Dimensions(WXHX D)237.8 mm (9.4”) x 148.6 mm (5.9”) x 35.5 mm (1.4”)
Net Weight788 g (2.42 lb.)
Supported Automotive ProtocolsISO9141-2, ISO14230-2,ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, ISO11898(Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN), SAE J2610,GM UART,UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6

MaxiDAS DS808

MaxiDAS
 DS808TS

MX808

MX808TS

Read Codes

Erase Codes

Live Data

ECU Information

Active Test

Service Functions

Complete OBD Diagnostics

Oil Service Reset

Parking Brake Pad Relearn After Replacement

Steering Angle Sensor Relearn

Battery Registration and Reset

Diesel Particulate Filter Regeneration

Tire Pressure Monitoring System

Basic

Complete

Basic

Complete

Immobilizer Function

Basic

Basic

Basic

Basic

Advanced TPMS Diagnostics
for Complete TPMS Health Check

--

--

Activate 98% of All Known TPMS Sensors

--

--

Program AUTEL MX-Sensors

--

--

Comprehensive OBD relearn coverage

--

--

On-screen Relearn Procedure

--

--

Battery Analysis

--

--

Videoscope

Processor

Quad-core 1.6GHz

Quad-core 1.6GHz

Quad-core 1.6GHz

Quad-core 1.6GHz

OS

Android 4.4.4

Android 4.4.4

Android 4.4.4

Android 4.4.4

Memory

1G + 64G

1G + 64G

1G + 64G

1G + 64G

Display

7" LCD

7" LCD

7" LCD

7" LCD

Battery

5000 mAh

5000 mAh

5000 mAh

5000 mAh

Internet Updatable

WiFi

WiFi

WiFi

WiFi

Multilingual Support

Historical Test Records

Save and Playback Data

Print Data via Windows PC or WIFI printer

Vehicle communication method

Wired

Wireless (bluetooth)

Wired

Wireless (bluetooth)


  • Description
  • • Extensive vehicle coverage for more than 80 US, Asian and European vehicle makes


    • Exceptional OE-Level system coverage for all electronic systems


    • Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, etc.


    • Smart AutoVIN technology for identifying vehicles easily


    • Automatic system and software updates with real-time push message notifications via Wi-Fi


    • Instant remote control tech support anytime, anywhere


    • Cloud-based MaxiFix online community provides proven filed fixes


    • Interactive Data Logging sessions enable direct contact with Autel Technical Support for first-hand troubleshooting of diagnostic bugs and errors


    • One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized


    • Convenient data management system for managing internal program applications and reviewing data


    • NEW!Compatible with Videoscope

  • Specifications
  • Recommended UseIndoor
    Operating SystemAndroid™ 4.4.4
    ProcessorCortex-A9 processor (1.6 GHz)
    Memory64GB
    Display7-inch LCD capacitive touchscreen with 1024x600 resolution
    Connectivity

    Mini USB 2.0

    USB 2.0

    Wi-Fi

    Micro SD card (supports up to 32GB)

    SensorsAmbient light sensor for brightness auto changing
    Audio Input/Output

    Input: N/A

    Output: buzzer

    Power and Battery

     3.7 V/5000 mAh lithium-polymer battery

     Charges via 5 VDC power supply

    Tested Battery LifeAround 4.5 hours of continuous use
    Battery Charging Input5 V/1.5 A
    Power Consumption500 mA (LCD on with default brightness, Wi-Fi on) @3.7 V
    Operating Temp-10 to 60°C(14 to 140°F)
    Storage Temp-20 to 70°C (-4 to 158°F)
    Operating Humidity5% - 95% non-condensing
    Dimensions(WXHX D)237.8 mm (9.4”) x 148.6 mm (5.9”) x 35.5 mm (1.4”)
    Net Weight788 g (2.42 lb.)
    Supported Automotive ProtocolsISO9141-2, ISO14230-2,ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, ISO11898(Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN), SAE J2610,GM UART,UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6
  • Video
  • Comparison

  • MaxiDAS DS808

    MaxiDAS
     DS808TS

    MX808

    MX808TS

    Read Codes

    Erase Codes

    Live Data

    ECU Information

    Active Test

    Service Functions

    Complete OBD Diagnostics

    Oil Service Reset

    Parking Brake Pad Relearn After Replacement

    Steering Angle Sensor Relearn

    Battery Registration and Reset

    Diesel Particulate Filter Regeneration

    Tire Pressure Monitoring System

    Basic

    Complete

    Basic

    Complete

    Immobilizer Function

    Basic

    Basic

    Basic

    Basic

    Advanced TPMS Diagnostics
    for Complete TPMS Health Check

    --

    --

    Activate 98% of All Known TPMS Sensors

    --

    --

    Program AUTEL MX-Sensors

    --

    --

    Comprehensive OBD relearn coverage

    --

    --

    On-screen Relearn Procedure

    --

    --

    Battery Analysis

    --

    --

    Videoscope

    Processor

    Quad-core 1.6GHz

    Quad-core 1.6GHz

    Quad-core 1.6GHz

    Quad-core 1.6GHz

    OS

    Android 4.4.4

    Android 4.4.4

    Android 4.4.4

    Android 4.4.4

    Memory

    1G + 64G

    1G + 64G

    1G + 64G

    1G + 64G

    Display

    7" LCD

    7" LCD

    7" LCD

    7" LCD

    Battery

    5000 mAh

    5000 mAh

    5000 mAh

    5000 mAh

    Internet Updatable

    WiFi

    WiFi

    WiFi

    WiFi

    Multilingual Support

    Historical Test Records

    Save and Playback Data

    Print Data via Windows PC or WIFI printer

    Vehicle communication method

    Wired

    Wireless (bluetooth)

    Wired

    Wireless (bluetooth)
