MaxiCOM MK908 Pro II

Autel MaxiCOM MK908P II is 10.1-inch touchscreen advanced diagnostics tablet powered by a Octa-core processor with 128GB of storage memory and runs on Android 10. The MK908P II can read/erase codes on all available systems, perform bi-directional active tests, view freeze frame, view and graph live data, and perform adaptations and coding on U.S., Asian and European vehicles, 1996 and newer.


  • image 0

• Qualcomm 660 Octa-core processor (2.2GHz Quad-core processor A73 + 1.8GHz Quad-core A53)


• 10.1-inch touchscreen Wi-Fi tablet


• Bluetooth-enabled MaxiFlash VCI/J2534 pass thru programming device


• Android 10.0 operating system


• Read/erase codes on all available systems


• View freeze frame, view and graph Live Data


• Perform bi-directional active tests


• Perform adaptations and coding


• AutoVIN and Auto Scan


• Share reports easily via email and text and Wi-Fi printing

Operating System

Android™   10.0

Processor

Qualcomm 660 Octa-core Processor (2.2GHz Quad-core A73 +   1.8GHz Quad-core A53)

Memory

4GB RAM & 128GB On-board Memory

Display

10.1-inch LED   screen with 1920x1200 resolution

Connectivity

Wi-Fi (802.11 a/b/g/n/ac)

USB   2.0 (2 USB TYPE-A ports and a Mini USB port)
BT V5.0 + BR/EDR

SD Card (Support up to 64GB)

HDMI

Camera (rear)

16 Megapixel, AF with Flashlight

Sensors

Gravity Accelerometer, Ambient Light Sensor (ALS)

Audio Input/Output

Microphone

Dual Speakers

3-Band 3.5 mm stereo/standard headset jack

Battery

15000mAh

Input Voltage

12V (9-24V)

Power Consumption

6.5 W

Operating Temp

0 to 50°C (32 to 122°F)

Storage Temp

-20 to 60°C (-4 to 140°F)

Housing

Strong plastic housing with protective rubber boot

Dimensions (W x H x D)

312mm(12.28")x208mm(8.18")x36mm(1.41")

Weight

NW: 1.48kg (3.26 lb)

Protocols

ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L-Line, Flashing Code,   SAE-J1850 VPW, SAE-J1850 PWM, CAN ISO 11898, Highspeed,   Middlespeed, Lowspeed   and Singlewire CAN, GM UART, UART Echo Byte Protocol,   Honda Diag-H Protocol, TP 2.0, TP 1.6, SAE J1939,   SAE J1708, Fault-Tolerant CAN


  • MaxiCOM MK908 II&MK908 Pro II User Manual

    Download

  • Description

    • • Qualcomm 660 Octa-core processor (2.2GHz Quad-core processor A73 + 1.8GHz Quad-core A53)


    • 10.1-inch touchscreen Wi-Fi tablet


    • Bluetooth-enabled MaxiFlash VCI/J2534 pass thru programming device


    • Android 10.0 operating system


    • Read/erase codes on all available systems


    • View freeze frame, view and graph Live Data


    • Perform bi-directional active tests


    • Perform adaptations and coding


    • AutoVIN and Auto Scan


    • Share reports easily via email and text and Wi-Fi printing

  • Specifications

    • Operating System

    Android™   10.0

    Processor

    Qualcomm 660 Octa-core Processor (2.2GHz Quad-core A73 +   1.8GHz Quad-core A53)

    Memory

    4GB RAM & 128GB On-board Memory

    Display

    10.1-inch LED   screen with 1920x1200 resolution

    Connectivity

    Wi-Fi (802.11 a/b/g/n/ac)

    USB   2.0 (2 USB TYPE-A ports and a Mini USB port)
    BT V5.0 + BR/EDR

    SD Card (Support up to 64GB)

    HDMI

    Camera (rear)

    16 Megapixel, AF with Flashlight

    Sensors

    Gravity Accelerometer, Ambient Light Sensor (ALS)

    Audio Input/Output

    Microphone

    Dual Speakers

    3-Band 3.5 mm stereo/standard headset jack

    Battery

    15000mAh

    Input Voltage

    12V (9-24V)

    Power Consumption

    6.5 W

    Operating Temp

    0 to 50°C (32 to 122°F)

    Storage Temp

    -20 to 60°C (-4 to 140°F)

    Housing

    Strong plastic housing with protective rubber boot

    Dimensions (W x H x D)

    312mm(12.28")x208mm(8.18")x36mm(1.41")

    Weight

    NW: 1.48kg (3.26 lb)

    Protocols

    ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L-Line, Flashing Code,   SAE-J1850 VPW, SAE-J1850 PWM, CAN ISO 11898, Highspeed,   Middlespeed, Lowspeed   and Singlewire CAN, GM UART, UART Echo Byte Protocol,   Honda Diag-H Protocol, TP 2.0, TP 1.6, SAE J1939,   SAE J1708, Fault-Tolerant CAN
