MaxiSYS MS908S II

MaxiSYS MS908S II is a 9.7-inch touchscreen advanced diagnostic tablet powered by an Octa-core processor with 128GB of storage memory running on Android 10.  Wirelessly communicates with vehicle via Bluetooth-enabled VCI.  The MS908S II can read/erase codes on all available systems, perform bi-directional active tests, view freeze frame data, view and graph live data, and perform adaptations and coding on U.S., Asian and European vehicles, 1996 and newer.


  • image 1

• Qualcomm 660 Octa-core processor (2.2GHz Quad-core A73 + 1.8 GHz Quad-core A53)


• 9.7-inch touchscreen Wi-Fi tablet


• Bluetooth-enabled Vehicle Communication Interface (VCI) with wireless range up to 70 meters


• 128G storage memory for maintaining of all needed brand diagnostics software


• Android 10.0 operating system


• Extensive vehicle coverage


• Comprehensive Service Menu for direct access to most commonly performed service tasks


• Read/Erase Codes on all available systems


• Perform bi-directional active tests


• View freeze frame data and view and graph systems live data


• Perform adaptations and coding

Operating System

Android 10

Processor

Qualcomm 660 Octa-core Processor (2.2GHz Quad-core A73 +   1.8GHz Quad-core A53)

Memory

4GB RAM & 128GB On-board Memory

Display

9.7 inch LED capacitive touch screen with 2048x1536 resolution

Connectivity

Wi-Fi (802.11 a/b/g/n/ac)

USB 2.0 (2 USB TYPE-A ports and a Mini USB port)
BT V5.0 + BR/EDR

SD Card (Support up to 64GB)

HDMI

Camera (rear)

16 Megapixel, AF with Flashlight

Sensors

Gravity Accelerometer, Ambient Light Sensor (ALS)

Audio Input/Output

Microphone
Dual Speakers
3-Band 3.5 mm stereo/standard headset jack

Power and Battery

11000 mAh 3.7 V lithium-polymer battery
Charging via 12 V AC/DC power supply with the temperature between 0°C and   45°C

Input Voltage

12V (9-24 V)

Power Consumption

6.5W

Operating Temp

0 to 50°C (32 to 122°F)

Storage Temp

-20 to 60°C (-4 to 140°F)

Dimensions(WXHX D)

300 mm (11.81”) x 220 mm (8.66”) x 50 mm (1.97”)

Weight

NW: 1.42 kg (3.13 lb.) GW: 8.052 kg (17.75 lb.)

Protocols

ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L-Line, Flashing Code,   SAE-J1850 VPW,
SAE-J1850 PWM, CAN ISO 11898, Highspeed, Middlespeed, Lowspeed   and Singlewire CAN, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP 2.0, TP 1.6,   SAE J1939, SAE J1708, Fault-Tolerant CAN



MaxiSys

MS908S Pro II

MaxiSys

MS908S II

MaxiSys

MS906TS

MaxiSys

MS906BT

MaxiSys

MS906

Function






All Systems DTC Scan

Service Function

Bi-Directional Control

Auto VIN Technology

ECU Coding

--

ECU Programming

--

--

--

--

MaxiFix Cloud-Based Info System

Data Manager

Shop Manager

Remote Support

Pre-scan Report & Post-scan Report

North America Only

North America Only

North America Only

North America Only

Print Feature

Multi-language Support

Coverage






Domestic/Asian/European   Coverage(1996-Present)

Hardware






Display Size

9.7"

9.7"

8"

8"

8"

Wireless VCI

MaxiFlash Elite

Wireless Diagnostic
    Interface

MaxiVCI V100

MaxiVCI V100

--

Battery Life

11000 mAh 3.7 V

11000 mAh 3.7 V

10000 mAh 3.7 V

10000 mAh 3.7 V

5000 mAh   3.7 V

Memory Storage

128GB

128GB

32GB

32GB

32GB

Connector Kit

Options






TPMS

--

--

--

--

Oscilloscope

--

Inspection Camera

--

ADAS

--


  • Description
  • • Qualcomm 660 Octa-core processor (2.2GHz Quad-core A73 + 1.8 GHz Quad-core A53)


    • 9.7-inch touchscreen Wi-Fi tablet


    • Bluetooth-enabled Vehicle Communication Interface (VCI) with wireless range up to 70 meters


    • 128G storage memory for maintaining of all needed brand diagnostics software


    • Android 10.0 operating system


    • Extensive vehicle coverage


    • Comprehensive Service Menu for direct access to most commonly performed service tasks


    • Read/Erase Codes on all available systems


    • Perform bi-directional active tests


    • View freeze frame data and view and graph systems live data


    • Perform adaptations and coding

  • Specifications
  • Operating System

    Android 10

    Processor

    Qualcomm 660 Octa-core Processor (2.2GHz Quad-core A73 +   1.8GHz Quad-core A53)

    Memory

    4GB RAM & 128GB On-board Memory

    Display

    9.7 inch LED capacitive touch screen with 2048x1536 resolution

    Connectivity

    Wi-Fi (802.11 a/b/g/n/ac)

    USB 2.0 (2 USB TYPE-A ports and a Mini USB port)
    BT V5.0 + BR/EDR

    SD Card (Support up to 64GB)

    HDMI

    Camera (rear)

    16 Megapixel, AF with Flashlight

    Sensors

    Gravity Accelerometer, Ambient Light Sensor (ALS)

    Audio Input/Output

    Microphone
    Dual Speakers
    3-Band 3.5 mm stereo/standard headset jack

    Power and Battery

    11000 mAh 3.7 V lithium-polymer battery
    Charging via 12 V AC/DC power supply with the temperature between 0°C and   45°C

    Input Voltage

    12V (9-24 V)

    Power Consumption

    6.5W

    Operating Temp

    0 to 50°C (32 to 122°F)

    Storage Temp

    -20 to 60°C (-4 to 140°F)

    Dimensions(WXHX D)

    300 mm (11.81”) x 220 mm (8.66”) x 50 mm (1.97”)

    Weight

    NW: 1.42 kg (3.13 lb.) GW: 8.052 kg (17.75 lb.)

    Protocols

    ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L-Line, Flashing Code,   SAE-J1850 VPW,
    SAE-J1850 PWM, CAN ISO 11898, Highspeed, Middlespeed, Lowspeed   and Singlewire CAN, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP 2.0, TP 1.6,   SAE J1939, SAE J1708, Fault-Tolerant CAN


  • Video
  • Comparison

  • MaxiSys

    MS908S Pro II

    MaxiSys

    MS908S II

    MaxiSys

    MS906TS

    MaxiSys

    MS906BT

    MaxiSys

    MS906

    Function






    All Systems DTC Scan

    Service Function

    Bi-Directional Control

    Auto VIN Technology

    ECU Coding

    --

    ECU Programming

    --

    --

    --

    --

    MaxiFix Cloud-Based Info System

    Data Manager

    Shop Manager

    Remote Support

    Pre-scan Report & Post-scan Report

    North America Only

    North America Only

    North America Only

    North America Only

    Print Feature

    Multi-language Support

    Coverage






    Domestic/Asian/European   Coverage(1996-Present)

    Hardware






    Display Size

    9.7"

    9.7"

    8"

    8"

    8"

    Wireless VCI

    MaxiFlash Elite

    Wireless Diagnostic
        Interface

    MaxiVCI V100

    MaxiVCI V100

    --

    Battery Life

    11000 mAh 3.7 V

    11000 mAh 3.7 V

    10000 mAh 3.7 V

    10000 mAh 3.7 V

    5000 mAh   3.7 V

    Memory Storage

    128GB

    128GB

    32GB

    32GB

    32GB

    Connector Kit

    Options






    TPMS

    --

    --

    --

    --

    Oscilloscope

    --

    Inspection Camera

    --

    ADAS

    --
