MaxiDAS DS808S-TS

Together with the ability to quickly read and clear DTCs for all available modules of the majority of the makes and models on the market, MaxiDAS DS808S-TS provides superior special functions, including Oil Reset, EPB (Electronic Parking Brake), SAS (Steering Angle Sensor), and BMS (Battery Management System). In addition to OBDII diagnostics and special functions, DS808S-TS can perform comprehensive TPMS services with ease.

  • image 1

• Extensive vehicle coverage for more than 80 US, Asian and European vehicle makes and models


• Exceptional OE-level system coverage for all electronic systems


• Read and erase codes, View and Graph Live data, Perform bi-directional Active Tests, Perform Adaptations


• AutoVIN technology automatically identifies vehicle make, model, and year


• 7-inch LCD capacitive touchscreen with 1024 x 600 resolution display


• Powerful Cortex-A55 processor (1.8 GHz) processor


• 64GB on-board memory for better performance


• Android 11 operating system for fast boot-up and multitasking


• Wi-Fi-enabled automatic software and system updates


• Instant remote control tech support anytime, anywhere


• Advanced TPMS diagnostics with DTC description


• At-a-glance TPMS status screen


• Activate all known TPMS sensors


• Program AUTEL MX-Sensor to replace TPMS 99% of sensors on vehicles today


• Comprehensive OBDII Relearn coverage


• Displays vehicle-specific Relearn instructions


• One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized


• Cloud-based Report Management allows you to view, save, print, and share reports on mobile phones, tablets, and computer browsers


• Compatible with Videoscope and MaxiBAS BT506 to perform Battery Tests and Analysis


Operating   SystemAndroid 11
ProcessorCortex-A55 quad-core processor (1.8GHz)
Memory4GB RAM & 64GB On-board Memory
Display7-inch LCD capacitive touchscreen with 1024x600 resolution
ConnectivityWi-Fi（802.11a/b/g/n/ac）
USB 2.0，Mini USB 2.0
Wireless BT V2.1+EDR
HDMI Type A
SD Card (Support up to 64GB)
SensorsLight sensor for brightness auto adjust
Audio Input/OutputInput: N/A
Output: Beep
Power and Battery3.7 V/5000mAh lithium-polymer battery
Charges via 5 VDC power supply
Input Voltage5 V/1.5 A
Operating Temp0 to 50°C (32 to 122°F)
Storage Temp-20 to 60°C (-4 to 140°F)
Dimensions(WXHX D)270.8 mm (10.0”) x 176.0 mm(6.9”) x 36.0 mm (1.4”)
Weight885g (2.31 lb.)
ProtocolsISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing   Code, SAE-J1850 VPW, SAE-J1850PWM,   ISo11898(Highspeed, Middlespeed, Lowspeed    and Singlewire CAN, fault-tolerant CAN) SAE J2610, GM UART UART Echo   Byte Protocol, Honda Diag-H Protocol,TP2.0,TP1.6



MaxiDAS DS808SMaxiDAS DS808S-BT MaxiDAS DS808S-TS
Read Codes√√√
Erase Codes√√√
Live Data√√√
ECU Information√√√
Active Test√√√
Service Functions√√√
Complete OBD Diagnositcs√√√
Oil Serive Reset√√√
Parking Brake Pad Relearn After   Replacement√√√
Steering Angle Sensor Relearn√√√
Battery Registration and Reset√√√
Diesel Particulate Filter Regeneration√√√
Tire Pressure Monitoring SystemBasicBasicComplete
Immobilizer FunctionBasicBasicBasic
Advanced TPMS Diagnostics for Complete   TPMS Health Check----√
Activate 98% of All Known TPMS Sensors----√
Program AUTEL MX-Sensors----√
Comprehensive OBD relearn coverage----√
On-screen Relearn Procedure----√
Battery Analysis--√√
Videoscope√√√
ProcessorQuad-core 1.8GHzQuad-core 1.8GHzQuad-core 1.8GHz
Operating SystemAndroid 11Android 11Android 11
Memory4G + 64G4G + 64G4G + 64G
Display7" LCD7" LCD7" LCD
Battery5000 mAh5000 mAh5000 mAh
Internet UpdatableWiFiWiFiWiFi
Multilingual Support√√√
Historical Test Records√√√
Save and Playback Data√√√
Print Data via Windows PC √√√
Vehicle communication methodWiredWireless (bluetooth)Wireless (bluetooth)


  • Description

    • • Extensive vehicle coverage for more than 80 US, Asian and European vehicle makes and models


    • Exceptional OE-level system coverage for all electronic systems


    • Read and erase codes, View and Graph Live data, Perform bi-directional Active Tests, Perform Adaptations


    • AutoVIN technology automatically identifies vehicle make, model, and year


    • 7-inch LCD capacitive touchscreen with 1024 x 600 resolution display


    • Powerful Cortex-A55 processor (1.8 GHz) processor


    • 64GB on-board memory for better performance


    • Android 11 operating system for fast boot-up and multitasking


    • Wi-Fi-enabled automatic software and system updates


    • Instant remote control tech support anytime, anywhere


    • Advanced TPMS diagnostics with DTC description


    • At-a-glance TPMS status screen


    • Activate all known TPMS sensors


    • Program AUTEL MX-Sensor to replace TPMS 99% of sensors on vehicles today


    • Comprehensive OBDII Relearn coverage


    • Displays vehicle-specific Relearn instructions


    • One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized


    • Cloud-based Report Management allows you to view, save, print, and share reports on mobile phones, tablets, and computer browsers


    • Compatible with Videoscope and MaxiBAS BT506 to perform Battery Tests and Analysis


  • Specifications
    • Operating   SystemAndroid 11
    ProcessorCortex-A55 quad-core processor (1.8GHz)
    Memory4GB RAM & 64GB On-board Memory
    Display7-inch LCD capacitive touchscreen with 1024x600 resolution
    ConnectivityWi-Fi（802.11a/b/g/n/ac）
    USB 2.0，Mini USB 2.0
    Wireless BT V2.1+EDR
    HDMI Type A
    SD Card (Support up to 64GB)
    SensorsLight sensor for brightness auto adjust
    Audio Input/OutputInput: N/A
    Output: Beep
    Power and Battery3.7 V/5000mAh lithium-polymer battery
    Charges via 5 VDC power supply
    Input Voltage5 V/1.5 A
    Operating Temp0 to 50°C (32 to 122°F)
    Storage Temp-20 to 60°C (-4 to 140°F)
    Dimensions(WXHX D)270.8 mm (10.0”) x 176.0 mm(6.9”) x 36.0 mm (1.4”)
    Weight885g (2.31 lb.)
    ProtocolsISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing   Code, SAE-J1850 VPW, SAE-J1850PWM,   ISo11898(Highspeed, Middlespeed, Lowspeed    and Singlewire CAN, fault-tolerant CAN) SAE J2610, GM UART UART Echo   Byte Protocol, Honda Diag-H Protocol,TP2.0,TP1.6


  • Video
  • Comparison

    		• MaxiDAS DS808SMaxiDAS DS808S-BT MaxiDAS DS808S-TS
    Read Codes√√√
    Erase Codes√√√
    Live Data√√√
    ECU Information√√√
    Active Test√√√
    Service Functions√√√
    Complete OBD Diagnositcs√√√
    Oil Serive Reset√√√
    Parking Brake Pad Relearn After   Replacement√√√
    Steering Angle Sensor Relearn√√√
    Battery Registration and Reset√√√
    Diesel Particulate Filter Regeneration√√√
    Tire Pressure Monitoring SystemBasicBasicComplete
    Immobilizer FunctionBasicBasicBasic
    Advanced TPMS Diagnostics for Complete   TPMS Health Check----√
    Activate 98% of All Known TPMS Sensors----√
    Program AUTEL MX-Sensors----√
    Comprehensive OBD relearn coverage----√
    On-screen Relearn Procedure----√
    Battery Analysis--√√
    Videoscope√√√
    ProcessorQuad-core 1.8GHzQuad-core 1.8GHzQuad-core 1.8GHz
    Operating SystemAndroid 11Android 11Android 11
    Memory4G + 64G4G + 64G4G + 64G
    Display7" LCD7" LCD7" LCD
    Battery5000 mAh5000 mAh5000 mAh
    Internet UpdatableWiFiWiFiWiFi
    Multilingual Support√√√
    Historical Test Records√√√
    Save and Playback Data√√√
    Print Data via Windows PC √√√
    Vehicle communication methodWiredWireless (bluetooth)Wireless (bluetooth)
